Description

The CD400SP IQ is our second generation walk-behind clipping machine, following the original reliable CD400SP.

This robust and self propelled machine has an EU stage 5 diesel engine from Hatz and a new intelligent control system. The CD400SP IQ logs the machine´s operational history so the owner can see the running hours and number of clips installed, whilst also monitoring the error log. The machine installs 4 clips simultaneously across two rails and has a sleeper lift function for new construction projects. The maneuvering unit is now cordless to be more flexible for the operator.

Benefits

  • Intelligent control system

    The intelligent control system simplifies operation and prevents incorrect usage. The system's automation ensures correct fastening and reduces the risk of damage to the shoulder and clips.

  • Informative display

    Information about the number of installed clips and operating hours allows for monitoring during work. Error code display simplifies troubleshooting in case of a potential system malfunction.

  • Efficient and durable

    Robust construction and a design that ensures both safety and efficiency in the work.

  • Reduced risk of personal injuries

    Protective cages over tools, as well as stops preventing clips from flying away, enhance safety for railway personnel.

Technical Data

CD400SP IQ

Clip: FC,FE, e-clip, PR401

Offset clips: Yes

Clipping: 4 clips per cycle

Unclipping: Up to 4 clips per cycle

Capacity: Up to 40 sleepers per minute

Sleeper lift: Up to 90 mm

Width: 2290 mm

Length: 3220 mm

Height: Work: 1830 mm / Transport 2110 mm

Weight: 3075 kg

Wheels: Ø 250 mm

Gauge: 1435 mm

Additional Information

CD300IQ is delivered with CE marking according to the standard:

  • Machinery directive: 2006/42/EC

  • Electromagnetic compatibility (EMC): 2014/30/EU

  • Safety of machinery - General principles for design Risk assessment and risk reduction: EN ISO 12100:2010

  • Safety of machinery – Electrical equipment - EN 60204-1

  • Safety of machinery – Control systems: EN ISO 13849-1:2015

Product Approval:

Network Rail: PA05/01477
